Hunting Down Gremlins in Your Signal Chain

1
00:00:00,220 --> 00:00:00,880
(Transcribed by TurboScribe.ai. Go Unlimited to remove this message.) Y'all ready to be history?

2
00:00:01,220 --> 00:00:01,520
Get started.

3
00:00:01,880 --> 00:00:02,180
Welcome.

4
00:00:02,320 --> 00:00:02,580
Hi.

5
00:00:02,780 --> 00:00:02,980
Hi.

6
00:00:03,220 --> 00:00:03,540
Hi.

7
00:00:03,700 --> 00:00:04,780
Hello, everyone.

8
00:00:05,220 --> 00:00:06,500
To the Pro Audio Suite.

9
00:00:06,600 --> 00:00:07,720
These guys are professional.

10
00:00:07,980 --> 00:00:08,660
They're motivated.

11
00:00:08,820 --> 00:00:10,240
With Tech the VO stars.

12
00:00:10,540 --> 00:00:12,240
George Whitten, founder of Source Elements.

13
00:00:12,280 --> 00:00:14,520
Robert Marshall, international audio engineer.

14
00:00:14,620 --> 00:00:16,640
Darren Robbo Robertson, and Global Voice.

15
00:00:16,660 --> 00:00:18,420
Andrew Peters, thanks to Tribooth.

16
00:00:18,420 --> 00:00:20,420
Austrian Audio, making passion heard.

17
00:00:20,540 --> 00:00:23,560
Source Elements, George the Tech Whitten, and Robbo

18
00:00:23,560 --> 00:00:25,180
and AP's international demos.

19
00:00:25,440 --> 00:00:27,740
To find out more about us, check theproaudiosuite

20
00:00:27,740 --> 00:00:28,400
.com.

21
00:00:28,400 --> 00:00:29,740
Line up, man.

22
00:00:30,040 --> 00:00:30,540
Here we go.

23
00:00:32,420 --> 00:00:34,680
And welcome to another Pro Audio Suite.

24
00:00:34,840 --> 00:00:37,740
Thanks to Austrian Audio, making passion heard.

25
00:00:38,120 --> 00:00:39,700
And Tribooth, time to get the code.

26
00:00:39,880 --> 00:00:41,700
T-R-I-P-A-P 200.

27
00:00:42,160 --> 00:00:44,500
That will get you 200 US dollars off

28
00:00:44,500 --> 00:00:45,280
your Tribooth.

29
00:00:46,160 --> 00:00:48,520
Now, I've been fiddling around and finding some

30
00:00:48,520 --> 00:00:51,140
weird shit going down in my studio when

31
00:00:51,140 --> 00:00:53,640
recording through the Grace M101.

32
00:00:54,600 --> 00:00:56,560
Some days I come in and I'm lucky

33
00:00:56,560 --> 00:00:57,700
to peak at minus 20.

34
00:00:57,820 --> 00:00:59,560
And then, like this morning when I was

35
00:00:59,560 --> 00:01:01,400
recording, it came in at minus 10.

36
00:01:02,340 --> 00:01:04,000
So I've done nothing different.

37
00:01:04,040 --> 00:01:05,060
I've changed no levels.

38
00:01:05,340 --> 00:01:07,760
I always stand pretty well in the same

39
00:01:07,760 --> 00:01:08,160
place.

40
00:01:08,240 --> 00:01:10,000
And I wouldn't have thought the microphone would

41
00:01:10,000 --> 00:01:13,480
be sensitive to that kind of like 12

42
00:01:13,480 --> 00:01:16,880
dB just by being a couple of inches

43
00:01:16,880 --> 00:01:19,160
in a different spot from the microphone.

44
00:01:19,400 --> 00:01:20,960
But I could be wrong.

45
00:01:21,520 --> 00:01:22,600
Anyone got any ideas?

46
00:01:22,600 --> 00:01:25,700
I would guess an analog pot.

47
00:01:26,220 --> 00:01:27,720
A failing analog pot.

48
00:01:28,180 --> 00:01:28,400
Maybe.

49
00:01:29,380 --> 00:01:30,860
This is like click and clack.

50
00:01:31,780 --> 00:01:32,020
Yeah.

51
00:01:32,400 --> 00:01:34,460
So when you lose one leg of a

52
00:01:34,460 --> 00:01:37,340
balanced fader or a balanced signal...

53
00:01:37,340 --> 00:01:38,060
That's 6 dB.

54
00:01:38,460 --> 00:01:39,400
That's 6 dB.

55
00:01:39,400 --> 00:01:40,080
Yeah, you lose 6.

56
00:01:40,100 --> 00:01:40,600
Yeah, not 10.

57
00:01:41,220 --> 00:01:43,860
But maybe he's not calculating exactly right.

58
00:01:44,880 --> 00:01:45,160
Yeah.

59
00:01:45,500 --> 00:01:47,180
But would that vary and go up and

60
00:01:47,180 --> 00:01:47,420
down?

61
00:01:47,520 --> 00:01:48,900
So one day it's louder and the next

62
00:01:48,900 --> 00:01:49,420
day it's quieter?

63
00:01:49,660 --> 00:01:51,840
Yeah, depending on humidity or...

64
00:01:51,840 --> 00:01:52,880
Well, intermittent cable.

65
00:01:53,220 --> 00:01:55,040
Like you're getting the balanced signal and then

66
00:01:55,040 --> 00:01:56,420
you're not getting the balanced signal.

67
00:01:56,660 --> 00:01:59,440
So one day it's coming through with all

68
00:01:59,440 --> 00:02:02,020
the two legs of the balanced signal and

69
00:02:02,020 --> 00:02:02,560
it's loud.

70
00:02:03,160 --> 00:02:04,820
And then another day the cable gets moved

71
00:02:04,820 --> 00:02:06,660
just enough, if it's a bad cable, that

72
00:02:06,660 --> 00:02:07,940
you're only getting one leg of the balanced

73
00:02:07,940 --> 00:02:09,699
signal and it's not loud.

74
00:02:10,060 --> 00:02:11,380
This is a good time to talk about

75
00:02:11,380 --> 00:02:14,280
tip ring sleeve connector problems.

76
00:02:14,280 --> 00:02:17,320
The reason why I like really true pro

77
00:02:17,320 --> 00:02:21,940
gear for road and production, rarely uses quarter

78
00:02:21,940 --> 00:02:23,240
inch plugs on.

79
00:02:23,620 --> 00:02:24,740
They're almost always XLR.

80
00:02:25,340 --> 00:02:29,940
Because the XLR jack design is dramatically better

81
00:02:29,940 --> 00:02:31,580
at making a reliable contact.

82
00:02:32,480 --> 00:02:35,380
The area of the pin that makes contact

83
00:02:35,380 --> 00:02:39,880
with the socket is dramatically better than a

84
00:02:39,880 --> 00:02:41,860
tip ring sleeve or any kind of a

85
00:02:41,860 --> 00:02:42,180
jack.

86
00:02:42,180 --> 00:02:44,880
The jacks only have one tiny point of

87
00:02:44,880 --> 00:02:45,340
contact.

88
00:02:45,480 --> 00:02:46,940
There's like a little metal finger, right?

89
00:02:46,980 --> 00:02:49,560
And it just touches the edge of the

90
00:02:49,560 --> 00:02:50,880
sleeve, you know?

91
00:02:51,080 --> 00:02:54,440
And if that exact point builds up any

92
00:02:54,440 --> 00:02:56,760
corrosion, you've all of a sudden lost that

93
00:02:56,760 --> 00:02:57,400
signal.

94
00:02:57,920 --> 00:02:59,780
So that's a part of your balanced signal.

95
00:02:59,880 --> 00:03:01,720
And that would cause the signal to drop.

96
00:03:01,960 --> 00:03:04,600
But it could come back if like, I

97
00:03:04,600 --> 00:03:08,180
don't know, you bump the desk or something

98
00:03:08,180 --> 00:03:08,620
moved.

99
00:03:08,640 --> 00:03:10,080
Or you spin the jack or something.

100
00:03:10,080 --> 00:03:11,520
So yeah, so I was about to say,

101
00:03:11,740 --> 00:03:14,620
easy cheap fix is you exercise your connectors.

102
00:03:15,140 --> 00:03:18,180
I like to joke that I'm exorcising them.

103
00:03:19,300 --> 00:03:23,900
But you're exercising the demons out of your

104
00:03:23,900 --> 00:03:27,780
jacks by twisting them around, exercising them.

105
00:03:27,920 --> 00:03:30,420
So just literally, some people pull in, out,

106
00:03:30,520 --> 00:03:31,220
in, out, in, out.

107
00:03:31,460 --> 00:03:33,020
If that's your thing, go for it.

108
00:03:33,020 --> 00:03:36,280
But I find that twisting them side to

109
00:03:36,280 --> 00:03:39,600
side is just as effective, if not more

110
00:03:39,600 --> 00:03:39,800
so.

111
00:03:39,920 --> 00:03:41,980
Just twisting them, rotating them back and forth.

112
00:03:42,860 --> 00:03:46,080
And you're burnishing the contact on the jack

113
00:03:46,080 --> 00:03:47,280
and on the slug.

114
00:03:48,040 --> 00:03:48,420
Yes.

115
00:03:50,420 --> 00:03:51,560
Jack-a-sutra.

116
00:03:52,080 --> 00:03:52,560
Yeah.

117
00:03:52,700 --> 00:03:55,880
So you'll notice that that clean burnishes the

118
00:03:55,880 --> 00:03:56,440
contacts.

119
00:03:57,320 --> 00:04:00,040
And you'll probably hear, if you're monitoring the

120
00:04:00,040 --> 00:04:01,900
input in your cans when you're doing this,

121
00:04:01,900 --> 00:04:04,520
you'll probably hear static when you're doing it

122
00:04:04,520 --> 00:04:05,100
at that time.

123
00:04:05,340 --> 00:04:07,200
And if the static, if you keep twisting

124
00:04:07,200 --> 00:04:08,840
it back and forth until the static goes

125
00:04:08,840 --> 00:04:11,800
away completely, then you've done your job.

126
00:04:11,900 --> 00:04:13,320
You've burnished the contact.

127
00:04:13,760 --> 00:04:15,720
Yeah, contact cleaning spray is nice too.

128
00:04:16,579 --> 00:04:18,399
But you don't always have that handy.

129
00:04:18,760 --> 00:04:22,200
And so just a twist is a way

130
00:04:22,200 --> 00:04:22,500
to go.

131
00:04:22,580 --> 00:04:24,120
I learned a hard lesson when I had

132
00:04:24,120 --> 00:04:27,260
my recording truck with quarter-inch patch bays.

133
00:04:27,860 --> 00:04:29,460
And all the patch bays were quarter-inch

134
00:04:29,460 --> 00:04:30,300
front and rear.

135
00:04:30,300 --> 00:04:33,400
So there was a lot of quarter-inch

136
00:04:33,400 --> 00:04:35,080
jacks going on, you know?

137
00:04:35,240 --> 00:04:36,420
I mean, like tons.

138
00:04:37,120 --> 00:04:38,760
And I just learned that that was a

139
00:04:38,760 --> 00:04:41,000
really bad choice for a remote recording truck

140
00:04:41,000 --> 00:04:43,560
because the thing's moving around, it's in different

141
00:04:43,560 --> 00:04:48,220
temperatures and humidities, and those things were unreliable.

142
00:04:48,300 --> 00:04:50,580
And also quarter-inches don't grab very well.

143
00:04:50,660 --> 00:04:52,500
No, they didn't have an extremely…

144
00:04:52,500 --> 00:04:53,960
Like you pull on that patch bay a

145
00:04:53,960 --> 00:04:55,500
little bit and the back of it pulls

146
00:04:55,500 --> 00:04:58,560
like slightly halfway out and now you've lost

147
00:04:58,560 --> 00:05:01,020
a contact or some stupid thing like that.

148
00:05:01,060 --> 00:05:02,500
Every time I got to a gig, I

149
00:05:02,500 --> 00:05:04,000
learned to reach around the back of the

150
00:05:04,000 --> 00:05:04,300
rack.

151
00:05:05,420 --> 00:05:06,520
Shove everything in.

152
00:05:06,760 --> 00:05:08,700
And I would reach around and I would

153
00:05:08,700 --> 00:05:10,840
push every jack back into the back of

154
00:05:10,840 --> 00:05:12,760
the panels just to be 100% sure

155
00:05:12,760 --> 00:05:14,820
I didn't have a bad contact.

156
00:05:15,020 --> 00:05:15,760
But that's where I learned.

157
00:05:15,860 --> 00:05:17,160
I was like, oh, that's why they have

158
00:05:17,160 --> 00:05:22,900
punch-down blocks and these less convenient connectors.

159
00:05:23,400 --> 00:05:25,160
The worst quarter-inch design, and I'll name

160
00:05:25,160 --> 00:05:27,020
them, Behringer's got a patch bay, quarter-inch

161
00:05:27,020 --> 00:05:29,900
patch bay, and the half-normaling, normal, fully

162
00:05:29,900 --> 00:05:31,340
normal switch is on the top.

163
00:05:32,340 --> 00:05:34,080
And there are these little slider switches that

164
00:05:34,080 --> 00:05:35,680
move really easily.

165
00:05:36,500 --> 00:05:38,560
And so it's in a rack and you're

166
00:05:38,560 --> 00:05:40,020
trying to pull this thing out and you're

167
00:05:40,020 --> 00:05:41,140
trying to pull it out in such a

168
00:05:41,140 --> 00:05:42,480
way that you don't pull every jack out

169
00:05:42,480 --> 00:05:43,080
the back of it.

170
00:05:43,160 --> 00:05:45,020
So inevitably what you do is you put

171
00:05:45,020 --> 00:05:47,000
your hands behind it and you try to

172
00:05:47,000 --> 00:05:48,960
push it out from the jacks behind, but

173
00:05:48,960 --> 00:05:50,740
you put your hands down there and then

174
00:05:50,740 --> 00:05:52,520
you move every single normaling switch.

175
00:05:52,520 --> 00:05:55,720
And you're like, oh my goodness, that's bad.

176
00:05:56,200 --> 00:05:57,380
I don't even, like, you have to go

177
00:05:57,380 --> 00:05:58,940
back to your design and figure out which

178
00:05:58,940 --> 00:06:01,200
one went where, worst designer.

179
00:06:01,480 --> 00:06:03,160
Well, I mean, I was asking Audient, before

180
00:06:03,160 --> 00:06:05,020
we hit record, I was asking Andrew if

181
00:06:05,020 --> 00:06:06,580
the plus 10 mode was engaged.

182
00:06:06,780 --> 00:06:09,640
So apparently, I'm looking at the console, a

183
00:06:09,640 --> 00:06:14,000
screenshot of the Audient ID console, and I'm

184
00:06:14,000 --> 00:06:16,160
not seeing that plus 10 feature.

185
00:06:16,740 --> 00:06:19,260
But maybe it's the smaller ID 4 or

186
00:06:19,260 --> 00:06:20,180
one of the other products.

187
00:06:20,180 --> 00:06:21,660
But I know for a fact, some of

188
00:06:21,660 --> 00:06:24,800
the Audients have a plus 10 boost.

189
00:06:25,260 --> 00:06:27,440
So that can get in your way too.

190
00:06:27,860 --> 00:06:31,280
So another thing we talked about is the

191
00:06:31,280 --> 00:06:33,180
fact that, and this is a little bit

192
00:06:33,180 --> 00:06:34,640
getting in the weeds, because it really only

193
00:06:34,640 --> 00:06:37,120
involves this interface.

194
00:06:38,060 --> 00:06:41,240
What's unique about the Audient ID 44 and

195
00:06:41,240 --> 00:06:43,480
the 22 and some others they make is

196
00:06:43,480 --> 00:06:44,800
they have what's called a send and a

197
00:06:44,800 --> 00:06:45,480
return jack.

198
00:06:45,480 --> 00:06:48,680
And those are handy because now you can

199
00:06:48,680 --> 00:06:52,060
insert audio through what's called the return jack

200
00:06:52,060 --> 00:06:55,240
and bypass the internal preamp.

201
00:06:55,700 --> 00:06:57,600
So that means you have one less point

202
00:06:57,600 --> 00:07:00,560
of failure or another knob to fiddle with.

203
00:07:00,960 --> 00:07:03,600
You just go from your external preamp into

204
00:07:03,600 --> 00:07:06,660
return, which is also a balanced connection, by

205
00:07:06,660 --> 00:07:10,900
the way, and you're bypassing a whole section

206
00:07:10,900 --> 00:07:11,460
of the circuit.

207
00:07:11,660 --> 00:07:11,760
The gain.

208
00:07:11,760 --> 00:07:13,100
So you don't have to worry about, yeah,

209
00:07:13,120 --> 00:07:14,480
another gain knob to worry about.

210
00:07:14,980 --> 00:07:15,460
Yeah.

211
00:07:15,720 --> 00:07:18,260
So that's something we're going to send you

212
00:07:18,260 --> 00:07:21,700
home, Andrew, and have you report back on

213
00:07:21,700 --> 00:07:24,140
the next show and tell us what fixed

214
00:07:24,140 --> 00:07:24,280
it.

215
00:07:24,480 --> 00:07:27,500
A, twisting the jacks, or B, connecting to

216
00:07:27,500 --> 00:07:28,340
the return jack.

217
00:07:28,840 --> 00:07:31,660
So George, curious, are those sends half normaled?

218
00:07:33,000 --> 00:07:34,820
My understanding is they're half normal.

219
00:07:34,920 --> 00:07:36,100
Can you plug into the send?

220
00:07:36,320 --> 00:07:37,700
So if you plug into send, it's going

221
00:07:37,700 --> 00:07:39,520
to interrupt the signal path.

222
00:07:40,520 --> 00:07:41,300
No, it won't interrupt.

223
00:07:42,120 --> 00:07:44,260
It will send it without interrupting it.

224
00:07:44,260 --> 00:07:44,540
Correct.

225
00:07:44,620 --> 00:07:45,360
It's half normal.

226
00:07:45,780 --> 00:07:46,760
Yes, it's half normal.

227
00:07:47,080 --> 00:07:48,180
What he's explaining.

228
00:07:48,420 --> 00:07:48,940
So it's like a Y.

229
00:07:49,700 --> 00:07:51,880
Yeah, the send jack on the back is

230
00:07:51,880 --> 00:07:52,780
sort of like a splitter.

231
00:07:53,020 --> 00:07:55,040
So if you have a mic plugged into

232
00:07:55,040 --> 00:07:57,520
an input, you can plug something into the

233
00:07:57,520 --> 00:07:59,600
send jack that you want to send audio

234
00:07:59,600 --> 00:08:00,520
to.

235
00:08:01,580 --> 00:08:04,320
Now, I used to use these occasionally as

236
00:08:04,320 --> 00:08:05,120
a phone patch.

237
00:08:05,200 --> 00:08:06,000
Like a direct out.

238
00:08:06,740 --> 00:08:08,900
Yeah, just to send the mic preamp out

239
00:08:08,900 --> 00:08:12,420
to a phone hybrid or an ISDN box

240
00:08:12,420 --> 00:08:13,840
or something else you have to send the

241
00:08:13,840 --> 00:08:14,500
audio to.

242
00:08:15,060 --> 00:08:15,740
Kind of handy.

243
00:08:16,260 --> 00:08:17,920
I'll give you the funny trick.

244
00:08:18,100 --> 00:08:21,380
So the same send return when it's TRS,

245
00:08:21,520 --> 00:08:22,940
so all on one jack, and so the

246
00:08:22,940 --> 00:08:23,740
separate send returns?

247
00:08:24,180 --> 00:08:25,760
Yeah, that's a different thing we're describing.

248
00:08:26,000 --> 00:08:26,320
Right.

249
00:08:26,440 --> 00:08:28,500
With the old Mackies, I think they reversed

250
00:08:28,500 --> 00:08:30,800
the send and the return so that you

251
00:08:30,800 --> 00:08:33,799
could purposely plug the quarter inch jack halfway

252
00:08:33,799 --> 00:08:37,039
in, not break the signal, and get a

253
00:08:37,039 --> 00:08:37,580
direct out.

254
00:08:37,700 --> 00:08:38,760
Yeah, that's right.

255
00:08:38,900 --> 00:08:41,000
I remember setting that up for people.

256
00:08:41,000 --> 00:08:43,760
Another cool hack with those insert jacks on

257
00:08:43,760 --> 00:08:47,020
the Mackie boards is my dad helped me

258
00:08:47,020 --> 00:08:50,080
build these little mic mute speaker mute boxes.

259
00:08:50,640 --> 00:08:53,240
And so they had one quarter inch cable

260
00:08:53,240 --> 00:08:55,560
that went into the insert, and then they

261
00:08:55,560 --> 00:08:57,200
had a pair of quarter inch ins and

262
00:08:57,200 --> 00:08:58,600
outs for the monitor's amp.

263
00:08:58,860 --> 00:09:00,740
So between the input and the output to

264
00:09:00,740 --> 00:09:01,260
the speakers.

265
00:09:02,100 --> 00:09:03,300
And so when you flick the switch in

266
00:09:03,300 --> 00:09:07,160
one position, the monitors were muted, but the

267
00:09:07,160 --> 00:09:09,860
signal would pass through the send return jack.

268
00:09:09,860 --> 00:09:12,820
You flick the switch, and it would cut

269
00:09:12,820 --> 00:09:15,080
the signal to the microphone, cutting off your

270
00:09:15,080 --> 00:09:17,100
mic, and turn on the speakers.

271
00:09:17,820 --> 00:09:19,080
Does that remind you of anything?

272
00:09:19,380 --> 00:09:20,520
Radio broadcast people?

273
00:09:21,980 --> 00:09:23,300
A few things, maybe.

274
00:09:23,760 --> 00:09:24,500
Yes, it does.

275
00:09:24,860 --> 00:09:26,120
Yeah, he did that with an insert jack?

276
00:09:26,220 --> 00:09:26,940
Yeah, yeah.

277
00:09:27,580 --> 00:09:29,260
I still have a couple of these boxes

278
00:09:29,260 --> 00:09:29,820
laying around.

279
00:09:30,580 --> 00:09:32,660
I will actually have to listen to our

280
00:09:32,660 --> 00:09:34,520
episode again and listen to that again to

281
00:09:34,520 --> 00:09:37,560
follow that, because I was not totally following

282
00:09:37,560 --> 00:09:37,800
that.

283
00:09:39,260 --> 00:09:41,840
So just to really quickly summarize, there's a

284
00:09:41,840 --> 00:09:43,920
quarter inch, the back of the box my

285
00:09:43,920 --> 00:09:46,700
dad would make, has five quarter inch jacks.

286
00:09:47,160 --> 00:09:49,560
One of them is strictly for the insert

287
00:09:49,560 --> 00:09:52,200
jack, and the other two are ins and

288
00:09:52,200 --> 00:09:54,560
outs for the left and right monitor speakers.

289
00:09:55,360 --> 00:09:59,360
So it goes between the monitor output of

290
00:09:59,360 --> 00:10:01,060
the mixer, or the control room out, as

291
00:10:01,060 --> 00:10:02,940
they call them on the Mackie, to your

292
00:10:02,940 --> 00:10:04,120
speakers or your amps.

293
00:10:04,120 --> 00:10:07,520
And then your insert cable, which is a

294
00:10:07,520 --> 00:10:10,400
standard tip ring sleeve quarter inch balanced cable,

295
00:10:10,600 --> 00:10:12,220
goes to the other jack.

296
00:10:12,300 --> 00:10:14,200
It's an unbalanced insert cable, right?

297
00:10:14,200 --> 00:10:15,700
It's technically unbalanced.

298
00:10:16,320 --> 00:10:19,180
The cable is a balanced cable, but it's

299
00:10:19,180 --> 00:10:21,800
doing two jobs, sending audio to and from

300
00:10:21,800 --> 00:10:22,600
the jack.

301
00:10:22,680 --> 00:10:23,400
It's a weird thing.

302
00:10:23,980 --> 00:10:26,480
And so all you're doing is breaking the

303
00:10:26,480 --> 00:10:29,140
connection between one set of jacks and the

304
00:10:29,140 --> 00:10:31,360
other, depending on which position the switch is

305
00:10:31,360 --> 00:10:31,680
in.

306
00:10:32,100 --> 00:10:33,640
And that way you never have to worry

307
00:10:33,640 --> 00:10:35,840
about your microphone feeding back with your monitor

308
00:10:35,840 --> 00:10:36,460
speakers.

309
00:10:36,640 --> 00:10:38,340
So whenever your mic is on, the monitors

310
00:10:38,340 --> 00:10:40,500
are off, and vice versa.

311
00:10:41,140 --> 00:10:43,120
So it was just a handy tool, and

312
00:10:43,120 --> 00:10:44,980
it's what they use in radio station consoles

313
00:10:44,980 --> 00:10:47,180
all the time, where the jack, you know,

314
00:10:47,260 --> 00:10:49,280
hits their on button, and the big giant

315
00:10:49,280 --> 00:10:51,700
speakers shut off the second they start talking.

316
00:10:52,180 --> 00:10:53,260
You know, that's common.

317
00:10:53,380 --> 00:10:54,960
So the switch was picking between the tip

318
00:10:54,960 --> 00:10:55,620
and the sleeve?

319
00:10:56,320 --> 00:10:57,640
Is that what it was switching between?

320
00:10:57,640 --> 00:10:59,300
Yeah, I don't remember what electronically was going

321
00:10:59,300 --> 00:11:01,500
on, but it was just breaking the connection.

322
00:11:02,320 --> 00:11:05,140
So if you broke the connection between the

323
00:11:05,140 --> 00:11:07,880
return, the signal wouldn't return back into the

324
00:11:07,880 --> 00:11:09,660
board, and so it wouldn't pass a signal.

325
00:11:09,800 --> 00:11:10,540
It was just dead.

326
00:11:10,840 --> 00:11:11,600
Yeah, wouldn't go to the speakers.

327
00:11:12,240 --> 00:11:12,440
Yep.

328
00:11:12,700 --> 00:11:14,720
So that was a fun little project.

329
00:11:15,200 --> 00:11:15,980
Talk about a tangent.

330
00:11:18,780 --> 00:11:20,780
And talk about a niche topic as well,

331
00:11:20,840 --> 00:11:23,180
because the fact that I've got these external

332
00:11:23,180 --> 00:11:25,940
preamps running through an ID44 is kind of

333
00:11:25,940 --> 00:11:28,560
weird and kind of niche.

334
00:11:28,560 --> 00:11:29,520
And you're just lucky.

335
00:11:30,620 --> 00:11:32,720
Well, Andrew, the other thing you can try

336
00:11:32,720 --> 00:11:34,780
is see if you get the same problem

337
00:11:34,780 --> 00:11:35,860
with a different preamp.

338
00:11:36,000 --> 00:11:38,400
So the whole thing with troubleshooting is always

339
00:11:38,400 --> 00:11:41,640
to pick a point and change something and

340
00:11:41,640 --> 00:11:43,260
see if the problem happens to the left

341
00:11:43,260 --> 00:11:45,120
or right of where you changed something.

342
00:11:45,280 --> 00:11:48,960
So if you change the preamp, and you

343
00:11:48,960 --> 00:11:52,300
still get that gain problem changing, or, you

344
00:11:52,300 --> 00:11:53,760
know, one day it's minus 10, the other

345
00:11:53,760 --> 00:11:55,760
day it's plus 20, or whatever the difference

346
00:11:55,760 --> 00:11:58,080
is, then you know the problem is not

347
00:11:58,080 --> 00:12:00,360
your preamp and it's everything after the preamp.

348
00:12:00,480 --> 00:12:03,100
So you've ruled out your microphone, and you've

349
00:12:03,100 --> 00:12:04,000
ruled out the preamp.

350
00:12:04,520 --> 00:12:07,100
Or if you use a different preamp, and

351
00:12:07,100 --> 00:12:09,140
you still have the same problem, then you

352
00:12:09,140 --> 00:12:11,320
know the problem is probably your microphone, because

353
00:12:11,320 --> 00:12:14,180
it happened with a different preamp, and therefore

354
00:12:14,180 --> 00:12:15,640
it's nothing from the preamp after.

355
00:12:15,980 --> 00:12:19,440
So that's called binary reduction, and it's really

356
00:12:19,440 --> 00:12:19,920
a great way to troubleshoot.

357
00:12:19,920 --> 00:12:21,700
I didn't know it was called binary reduction,

358
00:12:21,800 --> 00:12:22,200
good to know.

359
00:12:22,260 --> 00:12:23,720
I just called it process elimination.

360
00:12:23,720 --> 00:12:26,520
But yeah, you only want to change one

361
00:12:26,520 --> 00:12:27,600
variable at a time.

362
00:12:27,740 --> 00:12:29,020
That's the really crucial thing.

363
00:12:29,400 --> 00:12:32,100
If you don't change one component at a

364
00:12:32,100 --> 00:12:32,380
time...

365
00:12:32,380 --> 00:12:34,580
But change something in the middle.

366
00:12:35,360 --> 00:12:38,760
If you change something in the middle, you've

367
00:12:38,760 --> 00:12:40,500
now isolated to half the thing.

368
00:12:40,620 --> 00:12:42,460
If you start at the beginning, you have

369
00:12:42,460 --> 00:12:43,340
to do all the variables.

370
00:12:43,500 --> 00:12:45,480
But if you start in the middle, then

371
00:12:45,480 --> 00:12:47,560
you only have to do half of them

372
00:12:47,560 --> 00:12:48,320
on the next test.

373
00:12:48,380 --> 00:12:49,520
And if you split that in half, you

374
00:12:49,520 --> 00:12:50,720
only have to do half of those in

375
00:12:50,720 --> 00:12:51,340
the next test.

376
00:12:51,340 --> 00:12:53,080
So if you keep on splitting it in

377
00:12:53,080 --> 00:12:55,380
the middle, you'll speed up your troubleshooting.

378
00:12:56,240 --> 00:12:56,420
Beautiful.

379
00:12:56,800 --> 00:12:58,260
Well, that's my wig sorted then.

380
00:12:58,280 --> 00:12:58,880
That's a good one.

381
00:12:59,020 --> 00:13:00,580
That's stuff you learn the hard way if

382
00:13:00,580 --> 00:13:02,880
you're working in big studios with thousands of

383
00:13:02,880 --> 00:13:03,300
connectors.

384
00:13:04,260 --> 00:13:04,700
Yes.

385
00:13:05,040 --> 00:13:05,780
Yeah, exactly.

386
00:13:05,980 --> 00:13:07,800
When there's like 8 million points in between,

387
00:13:07,920 --> 00:13:09,400
you're like, which one of these 80 is

388
00:13:09,400 --> 00:13:09,540
it?

389
00:13:09,560 --> 00:13:11,360
I'm going to pick point number 40.

390
00:13:11,800 --> 00:13:13,280
Now I'll know if it's point 1 to

391
00:13:13,280 --> 00:13:14,980
40 or 40 to 80.

392
00:13:15,500 --> 00:13:17,480
Instead of starting at 1 and going through

393
00:13:17,480 --> 00:13:18,400
everything linearly.

394
00:13:18,840 --> 00:13:19,220
Interesting.

395
00:13:19,700 --> 00:13:20,180
Good point.

396
00:13:21,360 --> 00:13:22,320
I hope that helps.

397
00:13:22,460 --> 00:13:24,100
Well, that's interesting because the reason with the

398
00:13:24,100 --> 00:13:27,200
ID44 that I went for TRS was because

399
00:13:27,200 --> 00:13:29,580
if I'd gone XLR, then I'd be going

400
00:13:29,580 --> 00:13:30,920
using what I thought.

401
00:13:31,840 --> 00:13:33,420
Go back to what I was getting at.

402
00:13:33,620 --> 00:13:35,840
I thought if I use an XLR into

403
00:13:35,840 --> 00:13:39,060
the ID44, I'd be using the internal preamp,

404
00:13:39,320 --> 00:13:42,360
hence went for the DI with the TRS.

405
00:13:43,580 --> 00:13:46,460
The preamp still works, which is kind of

406
00:13:46,460 --> 00:13:46,760
annoying.

407
00:13:47,380 --> 00:13:49,200
I was hoping I was bypassing it.

408
00:13:49,200 --> 00:13:50,500
But if I go into the return on

409
00:13:50,500 --> 00:13:51,600
channels 1 and 2.

410
00:13:52,220 --> 00:13:53,860
It's so interesting.

411
00:13:54,000 --> 00:13:55,300
Each company has a different...

412
00:13:55,300 --> 00:13:56,580
If it's the line in, it's still hitting

413
00:13:56,580 --> 00:13:57,260
that preamp.

414
00:13:57,420 --> 00:13:57,640
Yeah.

415
00:13:57,920 --> 00:13:59,720
Each company has a different opinion on how

416
00:13:59,720 --> 00:14:00,260
to do that.

417
00:14:01,000 --> 00:14:04,000
Like the Apogee Duet, weirdly, didn't do it

418
00:14:04,000 --> 00:14:04,440
that way.

419
00:14:04,980 --> 00:14:06,800
And it made me scratch my head more

420
00:14:06,800 --> 00:14:08,300
than one time when I plugged in a

421
00:14:08,300 --> 00:14:10,280
quarter inch thinking that was the line in.

422
00:14:11,020 --> 00:14:12,800
And that was not the line in.

423
00:14:12,940 --> 00:14:15,460
It was the guitar or instrument in.

424
00:14:15,980 --> 00:14:18,040
Oh, it was the low Z in.

425
00:14:18,040 --> 00:14:20,400
Yeah, you had to use the XLR as

426
00:14:20,400 --> 00:14:21,000
the line in.

427
00:14:21,180 --> 00:14:22,480
And then there was a setting in the

428
00:14:22,480 --> 00:14:26,180
software inside their console that would switch it.

429
00:14:26,740 --> 00:14:28,500
No, it was like literally not just a

430
00:14:28,500 --> 00:14:29,240
pad, I don't think.

431
00:14:29,580 --> 00:14:30,400
Well, maybe it was.

432
00:14:30,760 --> 00:14:33,500
But it would switch modes and then it

433
00:14:33,500 --> 00:14:34,280
was a line input.

434
00:14:34,960 --> 00:14:37,220
But it was not logical to me at

435
00:14:37,220 --> 00:14:37,440
all.

436
00:14:37,860 --> 00:14:39,340
And to make matters worse, I rigged up

437
00:14:39,340 --> 00:14:41,120
a piece of gear for somebody a couple

438
00:14:41,120 --> 00:14:43,740
of weeks ago that's an audio video capture

439
00:14:43,740 --> 00:14:44,200
device.

440
00:14:44,200 --> 00:14:47,500
And it had two mic inputs, XLR and

441
00:14:47,500 --> 00:14:48,080
quarter inch.

442
00:14:48,960 --> 00:14:50,140
They were reversed.

443
00:14:50,640 --> 00:14:53,520
The XLR was line in, the quarter inch

444
00:14:53,520 --> 00:14:54,300
was the mic in.

445
00:14:55,080 --> 00:14:57,160
And I was like, who in the hell

446
00:14:57,160 --> 00:14:57,880
designed this thing?

447
00:14:57,880 --> 00:14:58,620
Is phantom power out a quarter inch?

448
00:14:59,380 --> 00:15:01,540
Is sending phantom power out a quarter inch?

449
00:15:01,660 --> 00:15:02,640
That's definitely not.

450
00:15:02,660 --> 00:15:03,800
No, it didn't have phantom power.

451
00:15:04,060 --> 00:15:05,160
It didn't even have phantom power.

452
00:15:06,480 --> 00:15:08,460
That speaks to the level of gear.

453
00:15:08,460 --> 00:15:11,300
Yeah, well, that's the problem with video gear

454
00:15:11,300 --> 00:15:12,580
that adds audio.

455
00:15:13,500 --> 00:15:15,560
And it's made for corporate users.

456
00:15:15,900 --> 00:15:17,640
So it was like a $1,500 piece

457
00:15:17,640 --> 00:15:17,960
of gear.

458
00:15:18,080 --> 00:15:18,920
It was expensive.

459
00:15:19,260 --> 00:15:22,560
And yet it had those two reversed and

460
00:15:22,560 --> 00:15:23,320
no phantom power.

461
00:15:23,680 --> 00:15:25,200
So we still had to use a Rodecaster

462
00:15:25,200 --> 00:15:28,040
mixer to give it a proper mic input.

463
00:15:28,240 --> 00:15:31,820
It was a crazy discovery that I did

464
00:15:31,820 --> 00:15:34,840
not think to read the manual because, you

465
00:15:34,840 --> 00:15:37,540
know, you sort of assume, you know.

466
00:15:38,560 --> 00:15:40,760
I mean, these days phantom power is like

467
00:15:40,760 --> 00:15:42,000
kind of assumed for.

468
00:15:42,540 --> 00:15:44,920
You can buy a $30 USB interface with

469
00:15:44,920 --> 00:15:48,160
phantom power, but this $1,500 device with

470
00:15:48,160 --> 00:15:50,180
two mic inputs had no phantom power.

471
00:15:50,900 --> 00:15:52,840
It was just, it just bizarre to me.

472
00:15:53,480 --> 00:15:56,840
And yeah, so never assume and with in

473
00:15:56,840 --> 00:15:57,080
doubt.

474
00:15:57,400 --> 00:15:58,460
That just makes you want to go back

475
00:15:58,460 --> 00:16:00,020
to the design meeting for that one.

476
00:16:00,020 --> 00:16:02,820
Yeah, RTFM, read the freaking manual.

477
00:16:03,500 --> 00:16:03,960
What's that?

478
00:16:04,180 --> 00:16:04,660
What's a manual?

479
00:16:04,840 --> 00:16:06,440
Is that like a car you drive a

480
00:16:06,440 --> 00:16:06,680
manual?

481
00:16:07,040 --> 00:16:08,880
Yeah, yeah, exactly.

482
00:16:10,380 --> 00:16:11,560
It's got a dog leg.

483
00:16:12,100 --> 00:16:14,360
The dog leg is called no phantom power.

484
00:16:16,720 --> 00:16:17,600
Yeah, exactly.

485
00:16:18,280 --> 00:16:19,960
That dog leg is cocked in the end.

486
00:16:20,640 --> 00:16:21,460
Well, that was fun.

487
00:16:21,560 --> 00:16:21,900
Is it over?

488
00:16:23,100 --> 00:16:24,740
The Pro Audio Suite.

489
00:16:24,800 --> 00:16:27,540
With thanks to Tribooth and Austrian Audio.

490
00:16:27,800 --> 00:16:29,160
Recorded using Source Connect.

491
00:16:29,500 --> 00:16:31,140
Edited by Andrew Peters.

492
00:16:31,300 --> 00:16:32,360
And mixed by Robbo.

493
00:16:32,540 --> 00:16:33,740
Got your own audio issues?

494
00:16:34,040 --> 00:16:35,540
Just ask Robbo.com.

495
00:16:35,720 --> 00:16:37,680
With tech support from George the Tech Whittam.

496
00:16:37,760 --> 00:16:39,760
Don't forget to subscribe to the show and

497
00:16:39,760 --> 00:16:41,980
join in the conversation on our Facebook group.

498
00:16:42,000 --> 00:16:44,140
To leave a comment, suggest a topic, or

499
00:16:44,140 --> 00:16:46,020
just say g'day, drop us a note at

500
00:16:46,020 --> 00:16:48,380
our website, theproaudiosuite.com.
